Vision X XIL-LPX325 5" Xmitter Low Profile Prime Xtreme LED Light Bar (25 Degrees)

 Vision X XIL-LPX325

The Xmitter Low Profile Xtreme Bar, using 5 Watt LEDs, achieves the beam pattern control of a 3 watt LED with the light output of a 10 watt LED, with 2x the output of the LoPro 3 Watt. It also boasts an extra low mounting depth and height and utilizes Vision X Prime Drive

Key Features:

- 25 Degree Narrow Beam

- 5" Long

- 3 5 Watt LED's

- 15 Watts

- Integrated Electronic Thermal Management (ETM)

- New Generation LED is Driven to 90% Efficiency

- PWM Integrated Dimming Circuitry

- Advanced Heat Sink Designed to prolong the life of the LEDs

Prime Drive - The Smart LED Bar

Electronic Thermal Management
ETM monitors the heat output of the LEDs and makes use of integrated Pulse Width Modulation circuitry in order to maintain safe operating temperatures in order to prolong the LED life span to its full 50,000 hour potential.
Pulse Width Modulation
The LoPro Xtreme Prime utilizes integrated Pulse Width Modulation (PWM) dimming circuitry to manage heat levels. PWM works by flashing the LED at a frequency faster than the human eye can detect, reducing the time that the LED is operating while still delivering 100% light output.

Slim, Compact Design- The Sleek LED Bar
Low Profile Design
The LoPro Xtreme Prime was designed to fit in the tightest places, with an extra compact body extruded aluminum body that doesn't sacrifice light output.
IP-68 Rated
The LoPro Xtreme Prime has achieved an ingress protection rating of IP-68, signifying that it is dust-proof and submersible in water up to 3 meters.
Proven Mounting System
The LoPro Xtreme Prime utilizes the Vision X signiture stud mounting system that allows for 15° of adjustability and helps to control vibration through the use of isolated rubber in the mount.

Mounting Depth: 1.00"

Height: 2.45"

Depth: 2.50"

Optic Purity: 90%

Driven At: 90%

Input Voltage: 10-46V

IP Rating: IP-68

Vibration Rating: 15.6G

Operating Temperature: -40 Celsius ~ +80 Celsius

Added Feautres:

• Weatherproof Deutsch Connector with Plug-and-Play Harness
• Billet Clamp Tube Frame Mounts Available
• Extruded 6061 Aluminum Housing
• Polycarbonate lens

Included:

• LoPro Xtreme Prime LED Light Bar
• Wiring Harness
• Installation Instructions
• Adjustment Allen Wrench
• Vision X Decal
